Sonata-Board
The Sonata-Board Single Board Computer (SBC) can serve both as a development platform and as an end product. In conjunction with the DART-MX91, DART-MX95, DART-MX93, DART-MX8M, DART-MX8M-MINI, DART-MX8M-PLUS, it offers even wider connectivity with additional interfaces such as Gigabit Ethernet PHY, camera interfaces, LVDS, PCIe, RTC etc.
Specifications
SoM Interface
3x 90pins B2B connectors
Compatible Products
Display
LVDS
2x Header, 18-bit / 24-bit
HDMI
2.0a via VAR-EXT-HDMI extension board (not included)
DSI
Header
RGB
RGB 666
Backlight Driver
PWM Control
Audio
Headphone
3.5 mm connector
Line - in
3.5 mm connector
Digital microphone
on-board
Touch Panel
Resistive
4-wire touch panel (4-pin FFC/FPC)
Capasitive
Capacitive touch panel (6-pin FFC/FPC)
Camera Interface
Serial Camera
Interfaces with the VCAM-5640S Camera Board (not included)
Security
TPM
Flash memory-based TPM 2.0 module
USB
USB Host
2 ports, Type A dual connector, USB2.0/USB3.0
USM OTG
1 port, Type C connector, USB3.0/2.0
Serial Ports
Debug port
USB-SERIAL bridge, USB-C type
RS232 (2)
Header
RS232 (3), (4)
Header
High-Speed Expansions
PCI-Express
Dual M.2 M-Key vertical connectors
SD-CARD
SD Card Socket
Additional Expansions
UART, CAN Bus
SPI, I2C
GPIOs
JTAG (header on SOM)
SAI, ESAI
SPDIF
GPT
QSPI, MQS, ADC, MLB, TAMPER
Ethernet Copper
2x 10/100/1000 Mbps, RJ45
Ethernet Fiber
1xSFP+ 10Gbps
Mechanical Specifications
Dimensions (W x L x H)
16.99 cm x 8.96 cm x 1.6 cm
Electronic Specifications
Supply voltage
12V DC input, 2.5 mm DC jack
RTC
From 12V input
