Specifications
SoM Interface
314pins MXM3 connector
Compatible Products
Display
LVDS
2x Header, 18-bit / 24-bit
HDMI
2.0a via Mini HDMI connector
DSI
Header
Backlight Driver
PWM Control
Audio
Headphone
2x 3.5 mm connector
Line - in
2x 3.5 mm connector
Digital microphone
2x on-board
Touch Panel
Capasitive
Capacitive touch panel (6-pin FFC/FPC)
Camera Interface
Serial Camera
Interfaces with the VCAM-5640S Camera Board (not included)
USB
USB Host
2 ports, Type A dual connector, USB2.0/USB3.0
2 ports, Type A dual connector, USB2.0
USM OTG
1 port, Type C connector, USB2.0
Serial Ports
Debug port
USB-SERIAL bridge, USB-C type
RS232 (1)
Header
RS232 (3), (4)
Header
High-Speed Expansions
PCI-Express
M.2 M-Key vertical connectors
SD-CARD
SD Card Socket
Additional Expansions
UART, CAN Bus
SPI, I2C
GPIOs
SAI, ESAI
SPDIF
GPT
QSPI, MQS, MLB
Ethernet Copper
2x 10/100/1000 Mbps, RJ45
Mechanical Specifications
Dimensions (W x L x H)
16.99 cm x 8.96 cm x 1.6 cm
Electronic Specifications
Supply voltage
12V DC input, 2.5 mm DC jack
RTC
From 12V input
